Type - 50
PCD ADJUSTABLE SCORING SAW BLADE
| Diameter | Teeth | Bore |
| 250mm | 60 | 25.4mm |
| Hook | Pinhole | Tooth Type |
| - | - | F-B |
| Material :- PCD ADJUSTABLE SCORING SAW BLADE |
| Machine :- Beam Saw machine |
| Application :- To Size Single or Multiple Panel for Optimal Quality Cutting and Long Edge Life of Products. |
| ORDER NO | DIA (mm) | THICK (mm) | BORE (mm) | THEETH | THOOTH TYPE |
| 44-250 022 060 | 250 | 2.2 | 25.4 | 60 | F-B |
| 44-250 022 080 | 250 | 2.2 | 25.4 | 80 | F-B |
| 44-305 022 060 | 305 | 2.2 | 25.4 | 60 | F-B |
| 44-305 022 080 | 305 | 2.2 | 25.4 | 80 | F-B |
| 44-355 026 084 | 355 | 2.6 | 25.4 | 84 | F-B |
| 44-400 035 096 | 400 | 3.5 | 25.4 | 36 | F-B |
| 44-450 038 096 | 450 | 3.8 | 25.4 | 96 | F-B |
