Type - 56
PCD CONICAL SCORING SAW BLADE FOR BEAM SAW MACHINE
| Diameter | Teeth | Bore |
| 150mm | 36 | 45mm |
| Hook | Pinhole | Tooth Type |
| - | - | Con./WZ |
| Material :- Chipboard, MDF, laminated Panels |
| Machine :- Beam Saw machine |
| Application :- Single or multiple Panels chip free quality cutting & long cutting life |
| ORDER NO | DIA (mm) | THICK (mm) | BORE (mm) | THEETH | THOOTH TYPE |
| 150 | 4.3-5.5 | 45 | 45 | 36 | Con./WZ |
| 56 - PT . PCD 16045 | 160 | 4.3-5.5 | 45 | 36 | Con./WZ |
| 56 - PT . PCD 18045 | 180 | 4.3-5.5 | 45 | 36 | Con./WZ |
| 56 - PT . PCD 20045 | 200 | 4.3-5.5 | 45 | 36 | Con./WZ |
| 56 - PT . PCD 20065 | 200 | 4.3-5.5 | 65 | 36 | Con./WZ |
